Extinguishing agent tank

Filling capacity

12 litres

Material

Stainless steel

Working pressure

Pressure

7,5 bar

Propellant gas bottle

Medium

Compressed air

Pressure cylinder

Filling pressure: 300bar

Volume: 2 litres

Technical parameters

Operating time

Appr. 25 sec.

Flow rate

24 litres/min

Operating temperature

Tmin +5°C; Tmax +60°C

Carrying device

Ergonomically shaped

Extinguishing gun

Changeover time

Appr. 3 sec. (jet to spray mode)

Lancing distance

Appr. 16 – 18m jet mode

Appr. 6 – 7m spray mode

Ratings (extinguishing performance)

A Fire Class

55 A (as per EN3)

B Fire Class

233 B (as per EN3)

IIB (EN 1866) (e.g.: with exting. agent Moussel C)

Dimensions

Weight empty

35 kg
